QSC KW181 Subwoofer

Building on the success of QSC’s K Series, the KW181 subwoofer, like the rest of QSC’s KW active loudspeakers, represents QSC’s next evolutionary step in wood enclosure loudspeakers. The system engineers created the KW series to feature all the groundbreaking electronic attributes of the popular K Series while at the same time designing a product that is both smaller and significantly lighter than previous wood enclosure models.

High Output
Like it K series predecessors, the QSC KW181 speaker features a QSC designed, 1000W (2 x 500) Class D power module. The loudspeaker is also fitted with an 18″ cone transducer of the same high-quality design.

DSP
Extensive signal processing is employed throughout the QSC loudspeaker, providing levels of sonic clarity and total output that defy all expectations for a speaker in this category:
Intrinsic Correction: first featured in QSC’s high-end line array products, it maps 65-75 spatially-averaged measurements to IIR and FIR filters that actively adjust time, frequency, and amplitude response to a maximally flat bandpass target. The result is an active speaker that behaves equally well across the entire sound field
DEEP and excursion limiting allow for extended low-frequency response by actively managing low-frequency transients without degradation of the underlying signal or adjacent frequencies
GuardRail protection, first introduced on QSC’s GX Series amplifiers protects both the amplifier module and your performance from unnatural and destructive clipping

Connectivity:
The QSC KW181 subwoofer speaker features dual balanced female XLR / 1/4″ line level‰input, dual balanced male XLR full-range line leave out, remote gain control via a potentiometer (sold separately), and a locking IEC power connector.

Control:
The QSC KW181 speaker has an LF switch which can be set to NORM, DEEP for additional bass extension. The rear panel LED switch can be set to POWER, illuminating the front-mounted LED when the QSC speaker is powered on, OFF for applications where it is not desirable to illuminate the front LED, or LIMIT which indicates to the system operator that the clip limiter circuit has been engaged during operation.

Premium-grade materials:
The QSC KW181 subwoofer, like all its KW Series brethren, is designed to withstand the rigors of professional use. Advanced construction processes, premium-grade Baltic birch cabinetry, ergonomic, cast aluminum handles, low-noise casters, and a highly protective steel grille provide for ease of transport and long-term durability. The QSC loudspeaker’s integrated M10 suspension points allow for flown applications and a threaded pole receptacle provides for a positive, wobble-free connection to a threaded speaker pole (included).
FEATURES
Speaker configuration
Active/passive: Active
Type: Subwoofer
LF driver: 18″
MF driver: N/A
HF driver: N/A
Power
Amplifier class: D
Wattage: 1000W continuous
Mixer/preamp: No
Audio
Frequency response: 39Hz – 145Hz
Coverage pattern: N/A
Max SPL: 132 dB
Inputs
XLR: 2 XLR/TRS
TRS:
TS:
RCA:
Output/thru
XLR: 2
TRS:
TS:
RCA:
SPEAKON:
Enclosure
Cabinet material: 15 mm painted birch ply
Width: 23.4″
Height: 20.1″
Depth: 29.9″
Weight: 88 lb.
Portable, profession low end extension. Order today and improve your PA exponentially.
